37
AppendixAppendix
Specifications
CF-18BHKZXDM/CF-18BHKZXKM
Intel ® Pentium M processor 900 MHz ULV
1 MB
256 MB (768 MB Max.)
UMA (64 MB Max.)
10.4 type (TFT)
256/65536/16M colors (640 x 480 dots/800 x 600 dots/1024x768 dots)
256/65536/16M colors (640 x 480 dots/800 x 600 dots/1024x768 dots/1280x1024
dots)*
2
40 GB* 3
Windows keyboard (82 keys)
Touch Pad
Touchscreen (Anti-Reflection, Stylus (included) touch capable)
Two Type I or Type II, or one Type III
3.3 V: 400 mA, 5 V: 400 mA
200-pin, SO-DIMM, 2.5 V, DDR-SDRAM, PC2100 Compliant
Dsub 9-pin Male
Miniature jack, 3.5 DIA
Miniature jack, 3.5 DIA
4-pin x 2, USB2.0
RJ-11 Data:56 kbps (V.92 & K56flex* 6 ) FAX:14.4 kbps
RJ 45 IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
802.11b
Dedicated 100-pin female
Monaural Speaker
AC ’97 2.1 Compatible, 18 bits full duplex stereo
Li-ion 7.4 V, 6.6 Ah
Approx. 7.5 - 8 h
Approx. 7 h
Approx. 3.5 h
Coin type lithium battery 3.0 V
Input : 100 V - 240 V AC, 50 Hz / 60 Hz Output : 16.0 V DC, 2.5 A
Approx. 18 W* 10 / Approx. 41 W (maximum when recharging in the ON state)
5 °C to 35 °C {41 °F to 95 °F}
30% to 80% RH (No condensation)
-20 °C to 60 °C {-4 °F to 140 °F}
30% to 90% RH (No condensation)
271 mm X 49 mm X 216 mm {10.3 " X 1.93 " X 8.5 "}
Approx. 2.0 kg {Approx. 4.5 lb.}
Model No.
CPU
L2 (Second) Cache Memory
Memory
Video Memory
LCD Type
Displayed Colors* 1
External Display
Hard Disk Drive
Keyboard
Pointing Device
PC Card Slot
Allowable current
RAM Module Slot* 4
Serial Port
Microphone Jack* 5
Interface Headphone Jack
USB Port
Modem
LAN
Wireless LAN
Expansion Bus Connector
Speaker
Sound
Battery Pack
Operating Time* 7
Charging Time* 7 Power On
Power Off
Clock Battery
AC Adaptor* 8
Power Consumption* 9
Environment In use Temperature
Humidity
Not in use Temperature
Humidity
Physical Dimensions* 11 (W X H X D)
Weight* 11
* 1 A 16M color display is achieved by using the dithering function.
Windows XP : 256 color depth and the resolution of 640 x 480 are not supported.
* 2 Maximum resolution depends on the specifications of the external display.
Windows XP : 256 color depth and the resolution of 640 x 480 are not supported.
* 3 1GB = 10 9 bytes
* 4 Only a RAM card designed for PC2100 can be added.
* 5 Use only a monaural condenser microphone.
* 6 The settings for the K56flex modem need to be changed according to the AT command.
* 7 Varies depending on the usage conditions.
* 8 The AC adaptor is compatible with power sources up to 240 V AC adaptor.
This computer is supplied with a 125 V AC compatible AC cord.
* 9 Approx. 0.7 W when the battery pack is fully charged (or not being charged) and the computer is off.
Approx. 1.5 W when the Wake up from LAN function has been enabled.
* 10 Rated power consumption.
* 11 The dimensions and weight do not include the hand strap.
Main Specifications
