23
APPENDIX D
(continued)
PATTON MODEL 2711 SERIES INTERFACE PIN ASSIGNMENT
M/34 Connector, Terminal Interface
Pin # Signal
A GND (Earth Ground/Shield)
B SGND (Signal Ground)
D CTS (DCE Source)
E DSR (DCE Source, Always On)
F CD (DCE Source)
L LL (Local Loop, DTE Source)
M TM (Test Mode Indicators, DCE Source)
N RL (Remote Loop, DTE Source)
P TD (Transmit Data +, DTE Source)
R RD (Receive Data +, DCE Source)
S TD/ (Transmit Data -, DTE Source)
T RD/ (Receive Data -, DCE Source)
U XTC (Transmit Clock +, DTE Source)
V RC (Receive Clock +, DCE Sourcce)
W XTC/ (Transmit Clock -, DTE Source)
X RC/ (Receive Clock -, DCE Source)
Y TC (Transmitter Clock +, DCE Source)
AA TC/ (Transmitter Clock -, DCE Source)
KK Aux. Power Input (+5VDC @ 300mA)
24
APPENDIX E
PATTON MODEL 2711 SERIES POWER SUPPLY INTERFACE
Main 5VC power jack (J1)
Center Pin:
+5VDC @ 300 mA
Outer Barrel: Ground
Auxillary Power: Supplied to Pin KK on V.35 connector
