21
APPENDIX C
PATTON MODEL 2711 SERIES FACTORY REPLACEMENT PARTS
AND ACCESSORIES
Patton Model # Description
2711/CM/120 ...................T1 Nx64 CSU/DSU(M/34 Male, 120VAC)
2711/CM/UI .....................T1 CSU/DSU (V.35 M/34 Male, UI)
07M2711..........................User Manual
22
APPENDIX D
PATTON MODEL 2711 SERIES INTERFACE PIN ASSIGNMENT
RJ-48C T1 (DS0) Network Interface
(RJ-48S Female Modular Jack)
Pin # Signal
1 RX Data (RING)
2 RX Data (TIP)
4 TX Data (RING)
5 TX Data (TIP)
}
}
From Network
To Network
