11
APPENDIX A
SPECIFICATIONS
A.1 ETHERNET CONNECTION
• Two Ethernet ports 10/100BaseTX; 802.3af
• Auto-Negotiating 10/100
• Supports Flow Control (IEEE803.X) for full duplex operation
• Supports back pressure for half duplex operation
• Store and forward
• Auto MDI-X
• 802.3af pass through
A.2 LED STATUS INDICATORS
• PoE/Power (Green): Glows solid when there is power to the unit
• Ethernet (Green): Flashes when passing traffic
Note See Table 1 on page 10 for LED details.
A.3 POWER
A.4 OPERATING TEMPERATURE
• 0-50°C
A.5 OPERATING HUMIDITY
Up to 90% non-condensing
A.6 POWER VS. DISTANCE
Model Voltage Current
2110/EUI 12VDC 200mA
2110/PSE/EUI-48 48VDC 500mA
2110/PSE/EUI 57VDC 350mA
Device Power
(MAX)
13W
(CLASS 3/0)
6.5W
(CLASS 2)
3.84W
(CLASS 1)
0W
(NO PoE
LOAD)
PoE Switch Range
(2110/EUI)
N/A 300m
(948ft)
400m
(1310ft)
600m
(1969ft)
48V Range
(2110/PSE/EUI-48)
300m
(948ft)
400m
(1310ft)
500m
(1640ft)
600m
(1969ft)
57V Range
(2110/PSE/EUI)
400m
(1310ft)
500m
(1640ft)
600m
(1969ft)
800m
(2625ft)
