MAG-EXT
Installation Manual
Page - 3 -
Parts List
This mount is shipped with all proper installation hardware and components. Make sure that none of these parts are
missing and/or damaged before beginning installation. If there are parts missing and/or damaged, please stop the
installation and contact Premier Mounts (800-368-9700).
Please review all WARNING and CAUTION statements (see Page 2) before beginning the installation of the
MAG-EXT Mount.
MAG-EXT
(Qty 1)
Mounting Legs (Qty 4)
M6 x 12mm
Security Screw
(Qty 8)
M3 Flat Washers
(Qty 4)
#14 X 2” Wood
Screw (Qty 3)
M5 x 12mm Security
Screw (Qty 4)
M4 x 12mm
Security Screw
(Qty 6)
M3 x 16mm Security
Screw (Qty 4)
¼” – 20 x 5/16”
Security Screw
(Qty 1)
M2.5 x 8mm Security
Screw (Qty 4)
Star Washers
(Qty 2)
Plastic Barrel Caps
(Qty 4)
