WPG-110 User Manual
DHCP
Server
Setup
You can select “auto” or “Disable” DHCP Server
♦ Start IP: The start IP address of DHCP Server.
♦ End IP: The end IP address of DHCP Server.
Wireless
Setup
Wireless LAN:
Allows you to Enable/Disable wireless function.
Region:
Default value is “Worldwide”. Choose where your location is.
SSID:
The default SSID is WPG-110. You also can change SSID name.
The max Length of string is 32 bytes.
SSID Broadcast:
If enable this option, every wireless station located within the
coverage of WPG-110 can discover it easily. If you are building a
public wireless network, enabling this feature is recommended. In
private network, “disable” SSID can provide better security.
Channel:
Channel: to set fixed channel or Auto. The “Auto” means after power
on WPG-110, it will scan all of wireless channel and select the clear
one automatically.
WEP:
You can select one of four format keys: 128-bit (ASCII: 13 chars)/
64-bit (ASCII: 5 chars)/ 128-bit (Hex: 26 digits)/ 64-bit (Hex:10 digits)
to encrypt transmitted data.
Key:
ASCII Characters (alphanumeric format) or Hexadecimal Digits (in
the “A-F”, “a-f” and “0-9” range) to be the WEP Key.
Gatekeeper
Gatekeeper is designed for ensuring the enterprise network security
within WPS box
♦ “All Block” can block Guest Users(through wireless) to
access all office network(LAN),
♦ “All Allow” can pass Guest Users(through wireless) to
access all office network
♦ “Internet Only” can block Guest Users (through wireless)
from office network (LAN) but still reserve internet
connection capability.
Confirmation and Save modifications
-
-
