– 52 –
Setup menus
SYSTEM menu
(continued)
Item Setting
No.
Superimposed
No.
Superimposed Description
display display
15 VO SYS 0000 –429
H (SD)* 1 : :
0429 0
: :
0858 429
16 SDI SYS 0000 –429
H (SD)* 1 : :
0429 0
: :
0858 429
17 V PHASE 0000 –190
H (SD)* 1 : :
0190 0
: :
0380 190
18 SCH COAR 0000 0
H (SD)* 1 0001 90
0002 180
0003 270
19 SCH FINE 0000 –32
(SD)* 1 : :
0032 0
: :
0064 32
20 AV PHASE 0000 –100
: :
0100 0
: :
0200 100
30 MENU 0000 OFF
LOCK 0001 ON
The underline on the setting item denotes the initial setting.
* 1 : With the SD output (SD tape playback or down-conversion output)
This enables the system phase to be adjusted in 74ns steps.
-: The phase is advanced.
+: The phase is delayed.
If setting operation is performed, the setting value does not
return to factory (default) setting.
This enables the SDI OUT system phase to be adjusted in
74ns steps.
-: The phase is advanced.
+: The phase is delayed.
If setting operation is performed, the setting value does not
return to factory (default) setting.
This enables the video system phase to be adjusted in 148ns
steps.
-: The phase is advanced.
+: The phase is delayed.
In the case of the SD down-converter output from the HD
playback tape (when the option has been installed), the video
phase is fixed.
This enables the SCH phase to be adjusted in 90-degree
steps.
-: The phase is advanced.
+: The phase is delayed.
(The SC phase changes but the H phase remains
unchanged.)
This enables the SCH phase to be adjusted in a total variable
range of +/-45 degrees or more.
-: The phase is advanced.
+: The phase is delayed.
(The SC phase changes but the H phase remains
unchanged.)
This enables the phase of the audio output to be adjusted to
the video output by 20.8us.
-: The audio output phase is moved ahead of the video output.
+: The audio output phase is delayed from the video output.
This selects whether to establish or release the system file
lock mode.
0: The system file lock is released (changes can be made).
1: The system files lock is engaged (no changes can be
made).
Video output signal adjustments
A control matrix of the sdjustments is shown below.
SYSTEM menu
10: ENCODER SEL
LOCAL
REMOTE
SYSTEM menu
11: SYS SC
LOCAL
REMOTE
LOCAL
REMOTE
SYSTEM menu
SYS SC
SYS H
Unit
Unit
External encoder
remote controller
SETUP menu
VIDEO LEVEL
CHROMA LEVEL
SET UP/HUE
Unit
External encoder
remote controller
Settings Item adjusted
