See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part from the PART LIST on page 14.
Note: Some small parts may have been preat-
tached. If a part is not in the parts bag, check to see if it has been preattached.
PART IDENTIFICATION CHART
M10 x 90mm Bolt (26)
M10 x 30mm
Screw (27)
M
1
0
x
2
0
0
m
m
B
o
lt
(3
1
)
M10 x 95mm Bolt (10)
M10 x 65mm Screw (30)
M10 x 70mm Screw (29)
M10 Nylon
Locknut (23)
M4 x 16mm
Self-tapping
Screw (8)
M6 Washer (25)
M
M6 x 70mm Screw (28)
M10 Washer (24)
5
