Subject to technical alterations, as well as to changes of the design and the colour
45
DIGITAL PRESENTERS
Visualizer DC 153 / Visualizer DC 160
Features
XGA resolution (1024x768) (DC 153)
SXGA resolution (1280x1024) (DC 160)
Progressive Scan CCD with 20 resp.
15 screen shots per second
Integrated memory for up to 48 resp.
64 screen shots
Autofocus and 3x zoom (DC 160)
The visualizers DC 153 and DC 160 combine
the flexible application of a swan-neck camera
with the professional quality of a visualizer. Flexible positioning
of the camera
Some objects are not
flat. Therefore the swan
neck can be rotated by
nearly 360
° and thus
objects can be viewed
from different angles.
Integrated illumination
The integrated lamp is
mounted on an extra
swan neck, which makes
it flexible. So it can be
positioned in a way that
light reflections are
avoided. The lamp life is
approx. 20,000 hours.
Mobile Mobile Desktop Desktop Ceiling
DC 153 DC 160 PS 400 PS 600 CL 500
7461-7 7461-10 7461-9 7461-4 7461-5
1/3” CCD 1/3“ CMOS 1/3” CCD 1/3” CCD 1/3” CCD
Progressive Scan Progressive Scan Progressive Scan Progressive Scan Progressive Scan
XGA 1024 x 768 SXGA 1280 x 1024 XGA 1024 x 768 XGA 1024 x 768 XGA 1024 x 768
20 15 20 22 20
64 48 80 64 64
– – Compact flash Compact flash –
„swan-neck“ „swan-neck“ 90 °/180°/270° 90 °/180°/270° –
– – – yes yes
16x digital 3x optical, 16x digital 12x optical, 4x digital 12x optical, 4x digital 12x optical, 16x digital
manual/autofocus motorized/autotocus motorized/autofocus motorized/autofocus motorized/autofocus
1 lamp 1 lamp 2 arms, lamp 2 arms, lamp illuminated working
background light background light surface
127x101 mm 127x101 mm lamp (100 W)
– – – yes yes
– – – optional, 3.5˝ diagonal –
VGA via DVI-I VGA via DVI-I VGA VGA VGA
mouse port (PS/2)
VGA/DVI-D or VGA/DVI-D or VGA, DVI, video, VGA, DVI, video, VGA, DVI-D
video video S-video, DC 12V/0.75A DC 12V/0.75A
RS 232, USB 1.1 RS 232, USB 1.1 RS 232, USB 1.1 RS 232, USB 1.1 RS 232, USB 1.1
Ethernet Ethernet
360 x 270 mm 340 x 270 mm 350 x 260 mm 350 x 260 mm see page 44
48 x 36 mm 48 x 38 mm 32 x 24 mm 32 x 24 mm see page 44
450 x 220 x 400 mm 460 x 220 x 400 mm 520 x 350 x 590 mm 520 x 350 x 590 mm 375 x 289 x 94 mm
ca. 2.2 kg ca. 2.3 kg ca. 5 kg ca. 5 kg ca. 6 kg
connection cables, connection cables, connection cables, connection cables, connection cables,
software, software, software Software, Software
IR remote control IR remote control IR remote control IR remote control IR remote control
Technical data:
Model
No.
Image sensor
Resolution in pixels
Picture sequence in seconds
Integrated memory
Slot for memory extension
Rotating head
Integrated seamless switcher
Zoom
Zoom / focus
Illumination
Image comparison/Split screen
LCD control monitor
Inputs
Outputs
Serial interface
Max. working surface
Min. working surface
Dim. in operation
Weight
Supplied with
