TROUBLE SHOOTING
20 88-V3840-09
Inserting the disc in reverse
direction
NO POWER
The car ignition switch is
not on
If the power supply is properly
connected to the car accessory
terminal,switch the ignition key
to "ACC"
The fuse is blown Replace the fuse
DISC CANNOT
BE LOADED
OR EJECTED
Presence of disc inside the
player. Remove the disc in the player,
then put a new one
Insert the compact disc with
the label facing upward
The disc is extremely dirty
or defective Clean the disc or try to play a
new one
Temperature inside the car
is too high Cool off or until the ambient
temperature return to normal
NO SOUND
Volume is in minimum Adjust volume to a desired level
Wiring is not properly
connected
Check wiring connection
THE RADIO
DOES NOT
WORK
The antenna cable is not
connected
Insert the antenna cable firmly
The signals are too weak Select a station manually
SYMPTOM CAUSE SOLUTION
SPECIFICATIONS
GENERAL
SIGNAL SYSTEM:
DISCS PLAYED:
AUDIO SIGNAL OUTPUT:
CHARACTERISTICS:
SUPPLY VOLTAGE: 12V DC (11V-15V)
CURRENT CONSUMPTION: <10 A
Compositive video 1.0Vp-p 75
(1)DVD-VIDEO Disc
5"(12 cm) single-sided, single-layer
5"(12 cm) single-sided, double-layer
(2)Compact Disc (CD-DA, VIDEO CD)
5"(12cm) disc
2ch&4ch line out
(1)Frequency Response 20 Hz - 20 KHz
(2)S/N Ratio 90 dB (JIS)
(3)Wow and Flutter
Below measurable limits
FM TUNER SECTION
AM TUNER SECTION
Tuning Range.....................87.5-107.9MHz
IF Range............................10.7MHz
Usable sensitivity(30dB)......15dB
Frequency Range................530-1710KHz
IF Range............................450KHz
Usable sensitivity(30dB)......45dB
NOTE:
Specifications and design are subject to
modification, without notice, due to
improvements in technology.
