1. General description
The TZA3046 is a transimpedance amplifier with Automatic Gain Control (AGC), designed
to be used in Fiber Channel/Gigabit Ethernet (FC/GE) fiber optic links. It amplifies the
current generated by a photo detector (PIN diode or avalanche photodiode) and converts
it to a differential output voltage. It offers a current mirror of average photo current for
RSSI monitoring to be used in SFF-8472 compliant modules.
The low noise characteristics makes it suitable for FC/GE applications, but also for
FTTx applications.
2. Features
■
Low equivalent input noise current, typically 126 nA (RMS)
■
Wide dynamic range, typically 2.5
µ
A to 1.7 mA (p-p)
■
Differential transimpedance of 7.5 k
Ω
(typical)
■ Bandwidth from DC to 1050 MHz (typical)
■
Differential outputs
■
On-chip AGC with possibility of external control
■
Single supply voltage 3.3 V, range 2.97 V to 3.6 V
■ Bias voltage for PIN diode
■
On-chip current mirror of average photo current for RSSI monitoring
■
Identical ports available on both sides of die for easy bond layout and RF polarity
selection
3. Applications
■
Digital fiber optic receiver modules in telecommunications transmission systems, in
high-speed data networks or in FTTx systems.
TZA3046
Fiber Channel/Gigabit Ethernet transimpedance amplifier
Rev. 01 — 19 May 2006 Product data sheet
CAUTION
This device is sensitive to ElectroStatic Discharge (ESD). Therefore care should be taken
during transport and handling.
