Power source 220-240 V AC, 50/60 Hz
Power consumption 28W (in operation) / approx. 7W (in standby mode)
Controls multifunctional remote control (VCR, DVD and TV) / VCR / DVD direct controls (main functions)
Disc Playback functions DVD-Video, DVD-R (R4.7), CD-Audio (CD-DA), Video-CD, CD-R/CD-RW
(CD-DA, Video-CD formatted discs), MP3
Video and Audio heads 4 heads video / 2 heads Hi-Fi
VCR Recording system 2 rotary heads, helical scanning system
Tape speed / Record and playback time SP: 23.39 mm/s , 240 min / LP: 11.7 mm/s , 480min (E240 cassette)
VCR Fast forward or fast rewind time
approx. 60 s (E180 cassette)
Video TV Colour system VCR: PAL 625/50 / DVD: PAL 625/50, PAL 525/60, NTSC
Video input and output level Pin jack/AV 1.0 V p-p (75 Ohm)
DVD S video output
Y output level: 1 Vp-p (75 Ohm) / C output level: PAL: 0.300 Vp-p (75 Ohm) NTSC: 0.286 Vp-p (75 Ohm)
Output connector: S terminal
DVD RGB video output RGB output level: 0.7 Vp-p (75 Ohm) / Output connector: AV1
Index
Specifications
Matsushita Electric Industrial Co., Ltd.
http://www.panasonic.co.jp/global/
UHF channel (21-69), 75 Ohm
Page
A-B repeat play 16
Add 10
ADVANCED SURROUND 17,19
Aerial 3
Analogue recording 12
ANGLE 19
AUDIO 5,19
Automatic Setting 3
AV input / AV Output (Scart) 3,11,12,18
AV LINK 11
BASS PLUS 17,19
Batteries 2
Bitstream 12,18,20
Brightness of VCR display 9
CANCEL 4,5,7,15,17
Channel 3,10
CHAPTER / Chapter review 15,16,19,20
Child lock
8,13,17,18,23
CINEMA 17
Clock 3,9
Country 3
CVC 8
DATE 3,9
Decoder 11
Delete 10
DIALOGUE ENHANCER 17,19
Digital Audio-output 12
Digital recording 12
DIMMED 9
DIRECT TV REC 6
DISPLAY 5,6,9,18
Disposal 2
Dolby Digital 12,13,18,20
DTS Digital Surround 12,13,18,20
DVD menus 15
Page
Dynamic range 18,20
EASY SETUP 13
EJECT 5
EP (SUPER LP) 6,7
Erasure prevention 8
EXIT 4
EXT LINK 11,21
Fast Forward, Fast Rewind 5,14
Field 18,20
Frame 18,20
Frame by frame viewing 14
INDEX (VHS Index Search System) 8
INPUT SELECT 4,11
Intro-Jet Scan 8,21
I-TIMER (INTELLIGENT TIMER) 7,21
JET SEARCH 5
Language codes 23
Language setting 9
Laser 2
Letterbox 13,18,20
LP, AUTO LP 6,7,21
MENU 5
Menu Operation 4
MESECAM 9
Mono sound 5,10
Move 10
MP3 menu 15
MPEG 12,13,18
NICAM sound 10
NTSC 8,18,21
OFF 6
ON 6
On Screen Displays / OSD Menu 9,18,19,23
ONE TOUCH MEMORY
17
OPTICAL 12,13
Page
OPEN/CLOSE 5
Optical digital audio lead 12,13,20
Password 13
PAL 60 18
Pan&Scan 13,18,20
PBC (Play Back Control) 16, 20
PCM Down conversion 12,18
PDC 6,21
Picture distorted 3,23
Playback 5,8,14,15,20
PLAY MODE 15
Playback Off Timer 8
POSITION MEMORY 16
PROG. / CHECK 6,7
Programme List 8
Programme playback 15
Progress Indicator 19
Q Link 3,6,21
Random playback 15
REC, REC/OTR, Recording 6,7
Receiver 11
REC CHECK 5
Remaining tape time (REMAIN) 5,6,7
Remote control 2,4,5,9,23
Repeat Playback 8,16
REPLAY 4,16
RESET 5
Restart Automatic settings 10
Resume function 16
RETURN 5
RF coaxial lead 3
RGB 12,18
Safety 2
Satellite Receiver 11
Scart 3,11,12,18
SEARCH 5,8,14
Page
SET UP 18
Shipping condition 10
ShowView 7,21
SKIP 16
Slow playback 5
Slow-motion playback 14
Sound system 10
Soundtrack language 18
SP 6,7
SQPB (S-VHS Quasi Playback) 9,21
Still mode / Still playback 5,18
Stop 5
Subtitles / Subtitle language 17,18,19
SUBWOOFER 12,17,19
SUPER LP (EP) 6,7,21
S-VIDEO 12
Synchronous recording 7
Tape counter 5
Tape length setting 9
Tape Speed 6
TITLE 16,19,20
TIMER, Timer recording 6,7
TOP MENU 15
TRACKING / V-LOCK 23
TV ASPECT 5
TV Operation 4
VCR / DVD OUTPUT 4,9
VCR display 9
VCR Operation 5
Volume 4
VPS 6,21
Warning 2
ZOOM 18
VCR RF modulated
VCR Horizontal resolution
more than 240 lines (SP)
VCR Signal-to-noise ratio video more than 43 dB (SP)
Audio Input level 0.5Vrms, more than 10 kOhm
Audio Output level VCR: 0.5Vrms, less than 1 kOhm / DVD: 2Vrms. (1 kHz, 0 dB) Output connector: Pin jack/AV, 2 ch (L/R), Subwoofer
VCR Dynamic range audio more than 90 dB (Hi-Fi sound tracks)
DVD Dynamic range audio DVD (linear audio): 96 dB / CD audio: 96 dB, Total harmonic distortion CD audio: 0.0025 %, S/N ratio: 115dB
VCR Audio frequency response 20 Hz to 20 kHz (Hi-Fi sound tracks)
DVD frequency response (linear audio) 4 Hz to 22 kHz (48 kHz sampling) / 4 Hz to 44 kHz (96 kHz sampling), CD audio: 4 Hz to 20 kHz
DVD Optical digital output
Optical terminal
Laser Pick up Wave length: 658 nm/790 nm / Laser power: Class 2 / Class 1
Norwegian Bølgelengde: 658 nm/790 nm / Laser-styrke: Class 2/Class 1 Ingen farlig strålning sendes ut (med sikkerhets-beskyttelse)
Operating temperature / humidity 5°C to 35°C / 35-80% relative humidity
Weight and Dimensions Approximate value: 5.2 kg / 430 (width) x 89 (height) x 345 mm (depth)
These specifications are subject to change without notice. [ENG] RQTD0035-A
