DC Power
The DC adapter supplied with the DC version of the model 1082/I plugs in a
DC source (nominal 48VDC) and plugs into the barrel power supply jack on
the rear of the 1082/I. Refer to Figure 10 below to make the proper connection.
Figure 10.
Power adapter
WARNING
There are no user-serviceable parts in the power supply
section of the Model 1082/I. Contact Patton Electronics
Technical support at +1 (301) 975-1007, via our web site
at www.patton.com, or by E-mail at
[email protected], for more information.
To Power
Supply Jack
To -48VDC
Source
-Vin
+Vin
