Installations and connections
Installing the ink film
1
Open the control panel.
2
Open the back cover.
O When the unit runs out of ink film, the following message will be displayed.
Install a new ink film.
Replacement ink film:
KX-FAN190 (15 m)
714
KX-FAN190W (15 m X 2) 1,208
4
If the ink film is slack, tighten it by
winding this gear (orange).
3
Insert the ink film.
Insert the orange
gear into the left slot
of the main unit.
Insert the white gear into the right slot
of the main unit.
5
Close the back cover pressing
“ ” down on both sides
until it clicks into place.
6
Close the control panel.
As of February 2007. Tax included.
