Wireless Base Station 11g True Turbo
1
2
3
4
Wireless
Internet Modem
Power
LAN4
To Modem
12V=1A
Reset
LAN3
LAN2
LAN1
EN
8
Install
Powering up the Wireless Router and connecting the
cables
Connect power to the Wireless Router
Connect the supplied power adapter to the 9V
1A port.
Connect Power Adapter to power socket.
Power light will turn on.
