40
Appendix
Specifications
Model No.
CPU
L2 (Second) Cache Memory
Memory
Video Memory
LCD Type
Displayed Colors* 3
External Display
Hard Disk Drive
Keyboard
Floppy Disk Drive
Slot PC Card Slot
Allowable current
(total for two slots)
RAM Module Slot* 6
Interface Parallel Port
External Display Port
Serial Port
Microphone Jack* 7
Headphone Jack
External Keyboard/Mouse Port
Expansion Bus Connector
USB Port
Modem
LAN
Wireless LAN
External Antenna Connector
Pointing Device
Sound
* 1 1 MB = 1,024 bytes
1 GB = 1,073,741,824 bytes
* 2 A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video Memory
cannot be set by the user.
* 3 A 16,000,000 color display is achieved by using the dithering function.
* 4 Maximum resolution depends on the specifications of the external display.
* 5 1 GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB .
* 6 Only a RAM card designed for PC2700 can be added.
* 7 Use only a monaural condenser microphone.
* 8 The settings for the K56flex modem need to be changed according to the AT command.
Main Specifications
CF-29ETKGZKM CF-29ETPGZKM CF-29E3KGZKM
Intel ® Pentium ® M Processor 1.3 GHz LV
1 MB * 1
256 MB * 1 (768 MB * 1 Max.) 512 MB * 1 (1 GB * 1 Max.) 256 MB * 1 (768 MB * 1 Max.)
UMA (64 MB * 1 Max.)* 2
65536/Approx. 16,000,000 colors (800 x 600 dots/1024 x 768 dots/1280 x 1024
dots/1600 x 1200 dots)*
4
40 GB * 5 60 GB * 5 40 GB * 5
87 keys
720 KB /1.44 MB (two-mode)
Two Type I or Type II , or one Type III
3.3 V : 400 mA
5 V : 400 mA
200 pin, 2.5 V , SO-DIMM, DDR SDRAM, PC2700 Compliant
Dsub 25-pin female
Mini Dsub 15-pin female
Dsub 9-pin male
Miniature jack, 3.5 DIA
Miniature jack, 3.5 DIA, Impedance 32
Ω
, Output Power 4 mW x 2
Mini DIN 6-pin female
Dedicated 80-pin female
4-pin, USB 2.0
RJ-11 jack, Data: 56 kbps (V.92 & K56flex* 8 ) FAX:14.4 kbps
RJ-45 jack, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
IEEE 802.11b/g compliant Frequency 2.4 GHz band
Dedicated 50
Ω
coaxial connector
Touch Pad Touch Pad
Touchscreen (Anti-Reflection, Stylus (included) touch capable)
WAVE and MIDI playback, Monaural Speaker (built in)
13.3 XGA type (TFT) with Touchscreen
65536/Approx. 16,000,000 colors (800 x 600 dots/1024
x 768 dots)
13.3 XGA type (TFT)
6 5 5 3 6 / A p p r o x .
16,000,000 colors (800 x
600 dots/1024 x 768 dots)
