EN
13
Out-of-range alert
When there is no connection between the units (e.g. one of the
units is switched off, units are set to different channels or
batteries are low), the out-of-range alert is activated and a
beeping sound is heard.
Infrared LEDs
When the camera unit is switched on, the infrared LEDs (A-1)
are automatically activated so the camera can also be used in
low light conditions. Images are displayed in black and white.
Using your baby cam
Other features
Connecting the monitor unit to your TV
SCART connection
1 Plug the Audio/Video connection cable supplied (B-17) into
both the AV OUT jack (B-13) of the monitor unit and the
SCART/RCA adapter(B-13) supplied.
2 Connect the adapter to the SCART connector of the TV.
RCA connection
1 Connect the single end of the Audio/Video RCA connection
cable supplied (B-17) to the AV OUT jack (B-13) of the
monitor.
2 Connect the audio/video plugs at the other end of the cable
to the appropriate audio/video inputs on your TV. Make sure
you insert the yellow plug into the Video input and the white
and red audio plugs into the L(eft) and R(ight) Audio inputs.
Note: If your TV is equipped with PIP (Picture In Picture) or Full
Dual Screen, you can continuously watch your baby while
watching TV.
Switching the night-light on and off
• Set the camera unit OFF/ON/ switch (A-4) to the
position to switch on the nightlight.
• Set the camera unit OFF/ON/ switch (A-4) to the OFF or
ON position to switch off the nightlight.
