Patton electronic IM1/I User Manual

Page 3

1.3 SERVICE

All warranty and nonwarranty repairs must be returned freight

prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Service at: (301) 975-1007, http://www.patton.com;
[email protected].

NOTE: Packages received without an RMA number will not be
accepted.

Patton Electronics’ technical staff is also available to answer any

questions that might arise concerning the installation or use of your
Model IM 1/I. Technical Service hours: 8AM to 5PM EST, Monday
through Friday.

WARNING!

This device is not intended to be

connected to the public telephone network.

APPENDIX B

IM1/I INTERFACE PIN ASSIGNMENT

10BASE-T Interface Pin Description

(RJ-45 Female Connector)

(DTE Configuration)

Pin #

Signal

TD + (data output from IM1/I)

TD - (data output from IM1/I)

RD +(data input to IM1/I)

no connection

RD - (data input to IM1/I)

no connection

Patton Electronics Company
