Audio Setting
Audio menu
1
Display the audio menu.
Press [VOL]
(PUSH SEL: Select).
Note: If no operation takes place for more than 5 seconds
in the audio menu (2 seconds in Main volume adjustment),
the display returns to the regular mode.
2
Select a mode to be adjusted.
Press [VOL] (PUSH SEL: Select).
3
Adjust.
Turn [VOL].
(Setting Range: 0 to 40, Default: 18)
: Up
: Down
(Setting Range: –12 dB to +12 dB by 2 dB,
Default: 0 dB)
: Increased
: Decreased
(Setting Range: –12 dB to +12 dB by 2 dB,
Default: 0 dB)
: Increased
: Decreased
(Setting Range: 15 levels each and 0 (center),
Default 0)
: Right enhanced
: Left enhanced
(Setting Range: 15 levels each and 0 (center),
Default 0)
: Front enhanced
: Rear enhanced
Volume
Bass
Treble
Balance
Fader
Note: If the fader is set to front, the pre-amp. output
(rear) is decreased.
[DISP] (Display)
exits from the audio menu.
[VOL]
selects a value in the audio menu.
(PUSH SEL) (Push to Select)
selects items in the audio menu.
