Philips Affinium LFM 200 - Manual (Page 3)

3
Type Power nominal
W
Color temperature
K
Color rendering index
CRI
Standard lighting level 1000 lux
LFM 200 59” center CW 25 5300-5900 ≥ 72
LFM 200 59” side 1 CW 15 5300-5900 ≥ 72
LFM 200 59” side 2 CW 15 5300-5900 ≥ 72
LFM 200 59” center NW 25 3900-4500 ≥72
LFM 200 59” side 1 NW 15 3900-4500 ≥72
LFM 200 59” side 2 NW 15 3900-4500 ≥72
High lighting level 1300 lux
LFM 200 59” center NW 35 3900-4500 ≥72
LFM 200 59” side 1 NW 22 3900-4500 ≥72
LFM 200 59” side 2 NW 22 3900-4500 ≥72
Affinium LED modules, 59” length
Lifetime
The lifetime of Affinium LED modules is rated at 50,000 hours (70% lumen maintenance).
Temperature
Operating temperature (performances): T
operating
min -13 ° F / max +50 ° F
Safety temperature (operating, no defects) T
safety
min -22 ° F / max +86 ° F
Storage temperature T
storage
min -22 ° F / max +140 ° F
Enhanced safety
In the event of unit damage, when used with a Safety Extra Low Voltage (SELV), energy-limited, class-2 Xitanium™ driver,
the Affinium LED system provides a safer operating environment than that of a fluorescent system.
Compliances and approvals
Affinium LED modules comply with all applicable regulations including:
ENEC • CE •
Product safety, class III • RoHS compliant •
WEEE • EU directive 2002/95/EC •
UL • NSF •
Type Power nominal
W
Color temperature
K
Color rendering index
CRI
Standard lighting level 1000 lux
LFM 200 67” center CW 31 5300-5900 ≥72
LFM 200 67” side 1 CW 20 5300-5900 ≥ 72
LFM 200 67”side 2 CW 20 5300-5900 ≥72
LFM 200 67” center NW 31 3900-4500 ≥ 72
LFM 200 67” side 1 NW 20 3900-4500 ≥ 72
LFM 200 67”side 2 NW 20 3900-4500 ≥ 72
High lighting level 1300 lux
LFM 200 67” center NW 44 3900-4500 ≥72
LFM 200 67” side 1 NW 28 3900-4500 ≥72
LFM 200 67” side 2 NW 28 3900-4500 ≥ 72
* Notes on lighting levels and energy savings:
Lighting levels are measured by a CCD camera at the center of the shelf at the center-most door of the case with a 5 inch distance between the
back of the module and the front of the merchandise. These measurements were taken at in-store lighting level conditions. Values for nominal
power and lighting levels can deviate by 20%, measured at -4°F (-20°C). Due to insufficient data points the values are best estimations.
Affinium LED modules, 67” length
