SPECIFICATIONS
Scanning system: PAL standard
(625 TV lines, 25 frames/sec.)
Interlace: 2:1 interlace
Image device: 1/3 inch solid state image device CCD
Picture elements: 798 (H) x 584 (V)
Effective picture elements: 753 (H) x 582 (V)
Synchronizing system: Manual internal sync/
Line lock switching
Resolution: 480 TV lines horizontally,
400 TV lines vertically
Video output level: 1.0 Vp-p/75 ohms, composite
Video S/N ratio: More than 48 dB
Minimum required illumination
(incandescent lighting):
Approx. 1.4 lux with a F 1.2 lens
Backlight compensation: ON condition only
Electronic iris function: Manual ON/OFF switching
Electronic iris range:
1.4 lux to 70,000 lux (F 1.2, lens)
2.0 lux to 100,000 lux (F 1.4, lens)
Flange-back: 12.5 mm ± 0.5 mm
White balance: ATW
Lens mount: CS mount
Environmental conditions:
Temperature: –10˚C ~ +50˚C
Humidity: less than 90% (no condensation)
Power supply: 24 V AC or 12 V DC
Power consumption:
24 V AC, 50 Hz: 3.2 W (with auto-iris lens)
2.5 W (without auto-iris lens)
12 – 15 V DC: 4.0 W (with auto-iris lens)
2.7 W (without auto-iris lens)
Weight: Approx. 160 g (without lens)
