Setup connections – Panasonic KX-FP105CX User Manual
Page 28
To the single telephone line
To the power outlet
(220–240 V, 50/60 Hz)
Telephone
line cord
Power cord
Handset cord
Connect to “LINE”.
28
Setup
Connections
1
Connect the handset cord.
2
Connect the telephone line cord.
3
Connect the power cord.
Note:
●
When you operate this product, the power outlet should be near the product and easily accessible.
●
If you want to connect an answering machine to the unit, see page 63 (KX-FP105 only).
