18 Replacement Parts List (Outdoor Unit)
REF. NO.
PART NAME & DESCRIPTION
QTY.
CU-C9DKU
CU-C12DKU
REMARKS
1
CHASSY ASS’Y
1
CWD50K2055A
←
0
2
SOUND PROOF MATERIAL
1
CWG302125
←
3
FAN MOTOR BRACKET
1
CWD541030
←
4
SCREW - FAN MOTOR BRACKET
2
CWH551059
←
5
FAN MOTOR, AC31W SINGLE
1
CWA951244
←
0
6
SCREW - FAN MOTOR MOUNT
3
CWH55406
←
7
PROPELLER FAN ASS’Y
1
CWH03K1006
←
0
8
NUT - PROPELLER FAN
1
CWH56053
←
9
COMPRESSOR (60HZ, 115V)
1
2R13S126A6AJ
2P19S126C1A
0
10
ANTI - VIBRATION BUSHING
3
CWH50077
←
11
NUT - COMPRESSOR MOUNT
3
CWH56000
←
12
CONDENSER
1
CWB32C1291
CWB32C1267
0
13
CAPILLARY TUBE ASS’Y
1
CWB15K1150
CWB15K1151
0
14
STRAINER
1
CWB11025
-
15
HOLDER COUPLING
1
CWH351015A
←
16
2-WAY VALVE (LIQUID)
1
CWB021147
←
0
17
3-WAY VALVE (GAS)
1
CWB011147
CWB011148
0
18
OVERLOAD PROTECTOR
1
CWA67C4718
CWA67C4719
19
HOLDER - O.L.P.
1
CWH7041200
←
0
20
TERMINAL COVER
1
CWH171011
←
21
NUT - TERMINAL COVER
1
CWH7080300
←
22
SOUND PROOF BOARD
1
CWH151022A
CWH151023A
23
CONTROL BOARD CASING
1
CWH102186
-
24
TERMINAL BOARD ASS’Y
1
CWA28K1123
←
0
25
ELECTRO MAGNETIC SWITCH
1
K6A1ALA00001
←
0
26
CAPACITOR - COMPRESSOR
1
XS371356FP-C
(35µF, 370VAC)
XS371506FP-B
(50µF, 370VAC)
0
27
HOLDER CAPACITOR
1
CWH30057
CWH30060
28
CAPACITOR - FAN MOTOR (8.0µF, 230V)
1
JS231805SPQH
←
0
29
CABINET SIDE PLATE (L)
1
CWE041044A
←
0
30
CABINET SIDE PLATE (R)
1
CWE041043A
CWE041073A
0
31
CABINET FRONT PLATE
1
CWE06K1036
←
0
32
WIRE NET COMPLETE
1
CWD04C1010
CWD04C1012
33
CABINET TOP PLATE
1
CWE031018A
←
34
CONTROL BOARD COVER
1
CWH131088
←
35
CONTROL BOARD COVER COMP
1
CWH13C1065
←
36
HANDLE
1
CWE161010
←
37
OPERATION INSTRUCTIONS
1
CWF564722
←
0
38
INSTALLATION INSTRUCTIONS
1
CWF612765
←
0
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
67
CS-C9DKU CU-C9DKU / CS-C12DKU CU-C12DKU
