ANH-P9R
NAVIGATION CD TUNER
Navigation Features
• 1-DIN installation
• Built-in RDS-TMC tuner for Traffic Information
• Built-in GPS receiver
• Selectable Voice Guidance: Male/Female*
• Menu language: UK English, German, French,
Italian, Flemish, Swedish, Spanish, Danish,
Dutch, Turkish
• Destination Memory: permanent memory for
approx. 50 destinations + 50 last destinations
• Route planner modes: shortest/fastest route
with/without motorways, with/without toll
roads, with/without ferries
• TMC support : Germany, North of Italy, The
Netherlands, Switzerland
• CD playback whilst navigating
• Address Search
• POI Search
CD-ROM Navigation Disc
• Application program and map data on 1 CD-ROM
• Coverage Area: Great Britain (Excl. Northern
Ireland), Germany, France, Italy, Benelux,
Austria, Switzerland, Spain, Portugal, Denmark,
Sweden,Monaco, Liechtenstein, Andorra, San
Marino, The Vatican
Tuner
• Adaptive RDS (PI, PS, AF, TP/TA)
• PTY (Search and Alarm)
• News interrupt feature
• Radio Text
• ARC 5 FM
• BSA (Best TP Station Auto Search)
• High speed PLL Synthesiser tuner
• PNS (Pulse Noise Suppressor)
• 24 Presets
• BSM (Best Stations Memory)
CD Player
• 8 x oversampling digital filter
• 1-bit D/A Converter
• Fast forward/reverse
• Track Search/Scan/Repeat
• Track/Manual search
• Random Play
• Last position memory
• Disc Title Memory
• CD Text
• CD-R/RW Playback
• CD-ROM
Audio
• MOSFET 50 W x 4 max. output power (watts)
• 4 x 27 W DIN output power watts
(DIN 45324, +B = 14.4 V)
• Built-in EEQ (Easy EQ) Plus system with 5-mode
factory preset equaliser, 2 custom preset
equalisers, 3-band parametric equaliser, 3-mode
Loudness, and LPF Network
• SFEQ (Sound Focus Equaliser)
• Direct Sub Drive
• Loudness
• Source level adjuster
• Fader
• Dual RCA Preout (Front + Rear or Subwoofer)
General
• Multi-CD Control
• ITS (Instant Track Selection)
• Source TV Control
• DAB Tuner Control
• External Source DVD Control
• External unit control via IP-Bus
• AUX-In (with optional CD-RB20)
• Remote control ready
• ISO Connector
• Digital Clock
• OEL Blue Display Illumination
• Soft Key Control
• Rotary volume
• Flap-type Front Panel
• Removable Front Panel
• Cellular telephone auto muting
• Flexible angle installation (0 — 30°)
* Male only: Turkish; Female only: Danish, Dutch,
Flemish
Features and Specifications
ANH-P9R
ACCESSORY LIST
• GPS Antenna (5 m cable included)
• Din Trim (Silver color)
• Din Installation holder
• Detach Case (hard)
• 30 cm Power Cord assy with iSO interconnector
Your local Pioneer dealer
Published by:
PIONEER EUROPE N.V.
Haven 1087, Keetberglaan 1, B-9120 Melsele
Tel.: + 32 (0)3 570 05 11
Copyright 2002 by Pioneer Europe N.V.
All rights reserved.
Features and specifications of the products described
or illustrated in this catalogue are correct at the time of
printing but could change as production changes might
occur. This catalogue may contain typographical errors
and the colours of the depicted products may deviate
slightly from reality. Consult your Pioneer dealer to
ensure that actual features and specifications match
your requirements. This catalogue may contain
references to products that may or will not be available
in your country.
Recording equipment and copyright: Recording equipment should be used only for lawful copying, and you are advised to check carefully what is
lawful copying in the country in which you are making a copy. Copy of copyright material such as films or music is unlawful unless permitted by a legal exception
or consented to by the rightowners.
GREAT BRITAIN: PIONEER GB Limited, Pioneer House, Hollybush Hill, Stoke Poges, Slough, Buckinghamshire SL2 4QP. Tel. +44/1753 789 789.
ICELAND: BRÆDURNIR ORMSSON HF, Lágmúli 8, P.O. Box 8760, 128 Reykjavik. Tel.: +354/55 32 800.
IRELAND: AUDIO VISION IMPORT, John F. Kennedy Drive, Dublin 12. Tel.: +353/1 240 5600.
MALTA: CACHIA & GALEA Ltd., Standard Bldgs., C. De Brockdorf Street, Msida MSD-02, Malta. Tel.: +356/33 38 61.
MILITARY: PIONEER ELECTRONICS DEUTSCHLAND GmbH, Military Sales Dept., Hanns-Martin-Schleyer-Str. 35, 47877 Willich, Germany. Tel.: +49/21 54 91 34 22.
LATVIA: BALTIC MULTI MEDIA SIA, Kr Barona Iela 16/18, 1050 Riga. Tel.: +371/761 01 11 (new office +371/728 62 96).
ESTONIA: ULKOKAUPAT EESTI AS., Kanali tee 1, 10 112 Tallinn. Tel.: +372/6 060 670.
ANH-P9R
FM
Frequency range (MHz)
87.5 - 108
Usable sensitivity 9
(dBf/µV, 75 ohms)
S/N ratio (dB)
70
Frequency response (Hz) 30 — 15,000
Stereo separation (dB) 40
MW
Frequency range (kHz)
531 — 1,602
Usable sensitivity (µV) 18
LW
Frequency range (kHz)
153 — 281
Usable sensitivity (µV) 30
CD
Frequency response (Hz)
5 — 20,000
S/N ratio (dB/1 kHz) 94
Dynamic range (dB/1 kHz) 92
GENERAL
Max. preout voltage (V/ohms)
2.2
AUDIO
02-C-A
N
H-P9L
E
AF-E
N
–
P
rinted
in
Belgium.
As
a
par
t
of
Pioneer’
s
commitment
to
a
cleaner
envir
onment
and
the
pr
otection
of
the
ea
rth,
this
catalogue
has
been
printed
on
chlorine-fr
ee
paper
.
NAVIGATION ANH-P9R
GPS RECEIVER
System
L1,/Acode GPS
SPS
(Standard Positioning Service)
Reception system 12 ch
Reception frequency 1,575.42 MHz
Sensitivity -130 dBm
Frequency approx. once a second
COMMON
Max.output impedance
-
Maximum current consumption 10A*
Power source DC 14.4V (10.8 — 15.1 V allowed)
Ground type Navigative Type
GPS ANTENNA
Antenna
Micro strip flat antena/
right-handed helical polarization
Antenna cable 5.0 m
DIMENSIONS
Main unit
180 x 50 x 157
GPS antenna 46 x 46 x 13
Remote controller 35 x 65 x 22 (option: CD-SR100)
WEIGHT
Main unit
1.5 kg
GPS antenna 115 g
Remote controller (Incl. Battery)* 50 g (Option: CD-SR100)*
* Audio only
