Technical Specifications
D-2
7510-A2-GB20-00
March 1997
Table D-1.
Model 7510 DSU Technical Specifications (2 of 2)
Item
Specifications
Network Interface
Data rates
LADS data rates
Services supported
56 kbps and 64 kbps clear channel (CC)
56 kbps and 64 kbps
4-wire service
Network Compatibility
ANSI T1.410-1992 and
AT&T Technical Reference
62310-1993
56 and 64 kbps meeting desired loop loss
DTE Data Port Interface
34-pin V.35 connector
Table D-2.
Model 7510 DSU LADS Connection Distances
Wire Diameter (AWG)
Data Rate
(kbps)
19 Gauge
(.0359
I or
.9122 mm)
22 Gauge
(.0253
I or
.643 mm)
24 Gauge
(.0201
I or
.511 mm)
26 Gauge
(.0159
I or
.404 mm)
56
10.84 mi
(17.45 km)
6.4 mi
(10.3 km)
4.50 mi
(7.24 km)
3.34 mi
(5.37 km)
64
10.69 mi
(17.2 km)
6.06 mi
(9.76 km)
4.47 mi
(7.2 km)
3.20 mi
(5.15 km)
