A
Main unit
Remote control
Location of controls/Connection to other equipment
Battery
compartment
Hold switch
Headphone jack
Open switch
Tuning/Skip/Search
Play/Pause
Stop/
Turn off
Volume control
To DC IN jack
Monaural/Stereo
Sound quality selection
Memory/Recall/Digital
Re-master/Anti-skip
mode selection
Audio system
Adjust the
volume on the
audio system.
AC adaptor
Purchase RP-AC46 for .
Connect the AC adaptor to the
household AC outlet first.
SL-SV570 SL-SV573J
Household AC
outlet
Car power adaptor (SH-CDC9) (not included)
You can recharge the batteries
with this connection. SL-J610V
Car audio
To CD or AUX
terminals
Audio cable (not included)
Car stereo cassette adaptor (SH-CDM10A)
(
not included)
Sensitivity control/
Play mode selection
Some cannot be
connected.
2
Lens
≥ 1 AC adaptor: RFEA403C-2S
≥ 1 Active speaker system:
Speaker (R ch): RFKNLJ610VP1
Speaker (L ch): RFKNLJ610VP2
Unit base: RFE0132
For U.S.A.
≥ 1 Pair of stereo headphones: L0BAD0000164
For Canada
≥ 1 Pair of stereo earphones: L0BAB0000182
≥ 1 Pair of stereo headphones: L0BAD0000165
≥ 1 Wired remote control: N2QCBD000011
≥ 1 Jogger soft case: RFC0081-K
≥ 2 Alkaline batteries
≥ 1 Pair of stereo headphones: L0BAD0000164
SL-SV570
SL-SV573J
SL-J610V
Check the packing carton for these accessories.
Use numbers indicated when ordering replacements or optional accessories
from your Panasonic dealer.
In U.S.A. to order accessories, refer to “Accessory Purchases” on page 4.
Tuning mode selection
Tuner on/
Band selection
Display panel
Plug type:
3.5 mm (
1 / 8 in.) stereo
Noise may occur when using the car power
adaptor and listening to the radio.
Earphones: for Canada
SL-J610V
Headphones:
for U.S.A.
SL-SV570 SL-SV573J
SL-J610V
Turn off this unit and the other equipment before connection.
References to the remote control apply only to SL-SV573J.
Supplied Accessories
Play/Stop/Turn off
Volume control
Hold switch
Tuning/Skip/
Search Tuner on/off/
Band selection
Plug type:
3.5 mm
(
1 / 8 in.) stereo
∫
Using jogger soft case SL-SV573J
∫
Using headphones
≥ Before jogging with this unit, allow sufficient time for the memory buffer to fill
up completely (CD-DA: 45 seconds, MP3: 100 seconds).
≥ This unit is designed for light jogging, but not for serious running. It may
occasionally skip if used by an aggressive runner, or by someone with a
heavy, jarring stride.
≥ Do not machine wash.
Fading and loss of shape can occur.
≥ Do not drop the unit as the soft case cannot protect the unit and CD from
damage.
Fasten the belt securely.
Insert so buttons
are facing away
from your body.
≥ Set the unit’s volume to 10-15.
≥ Use the main unit to avoid beep sounds heard
when operating the remote control buttons.
SL-SV573J
Through to headphone jack (Ë) SL-SV573J
Directly to headphone jack (Ë) SL-SV570 SL-J610V
Connect the remote control to the main unit first.
SL-SV573J
SL-SV573J
≥ Set the unit’s volume to 10-15.
