201
6
Appe
ndix
Exposure Meter/
Metering Range
TTL multi (16)-segment metering, Metering range from EV 1 to
EV 21.5 at ISO 200, with 50 mm f/1.4 lens, Center-weighted and
Spot metering mode can be set
EV Compensation
±2.0 EV (Selectable between 1/2 EV and 1/3 EV for Exposure
setting steps)
AE Lock
Button type (timer type default: 20 sec. or continuous as long as
the shutter button is halfway pressed)
Built-in Flash
P-TTL built-in flash with serial control, GN 15.6 (ISO 200/m),
Angles of coverage: 18 mm lens angle of view, Flash
synchronization speed range at 1/180 sec. and slower, Daylight-
sync flash, Slow-speed-sync flash, ISO range = P-TTL: 200 to 3200
External Flash Sync
Hot shoe with X-contact, which couples with Pentax dedicated auto flashes,
ISO range = P-TTL: 200-3200, Automatic flash, Red-eye reduction flash
function, High-speed-sync, wireless-sync with PENTAX dedicated flash.
Custom Function 18 functions can be set
Time Function World Time settings for 70 cities (28 time zones)
Dust Removal
SP coating and CCD operations for dust removal. Can be set to
operate when the camera is turned on.
Power
Two CR-V3, four AA lithium, AA Ni-MH rechargeable, or AA
alkaline batteries
Battery Exhaustion
Battery exhaustion symbol ? is lit. (The shutter is locked and
no indication appears in the viewfinder when ? starts blinking)
In/Out Port
USB/Video terminal (USB 2.0 (high speed compatible)), DC
input terminal, Cable switch terminal
Video Output Format NTSC/PAL
PictBridge
Compatible printer PictBridge-compatible printer
Print mode Single Image, All Images, DPOF AUTOPRINT
Dimensions and
Weight
129.5 mm (W) × 92.5 mm (H) × 70 mm (D)
570 g (body only), 645 g (with two CR-V3 and an SD Memory Card),
665 g (with four AA alkaline batteries and an SD Memory Card)
Accessories
Hot shoe cover F
K
, Eyecup F
O
, ME viewfinder cap, Body mount
cover, USB Cable I-USB17, Video cable I-VC28, Software (CD-
ROM) S-SW55, Strap O-ST53, Four AA alkaline batteries,
Operating Manual (this book) and PENTAX PHOTO Browser 3/
PENTAX PHOTO Laboratory 3 Operating Manual
Languages
English, French, German, Spanish, Italian, Swedish, Dutch,
Russian, Korean, Chinese (Traditional / Simplified) and Japanese
Specifications for Remote Control F (Optional)
Remote Control
Infrared remote control unit, captured about three seconds after remote
control shutter button is pressed or immediate capture on pressing the
button, operating distance = within approx. 5 m in front of the camera.
Power One lithium battery (CR1620)
Dimensions 22 mm (W) × 53 mm (H) × 6.5 mm (D)
Weight 7 g (including battery)
