MAX PRO-SERIES Communication/Configuration Specifications (continued)
USA & Canada (800) 472-5555 • (707) 283-5900 • Fax (707) 283-5901 12
?ID
?TRIGSTAT
?OUTLETSTAT
?POWERSTAT
?VOLTAGE
?CURRENT
?HELP
Request that the unit identify itself.
Request the on/off status of the front panel
button and input trigger.
Request the on/off status of the
outlet banks and output trigger.
Request the status of the input voltage.
Request the line voltage.
Request the input current draw.
Request a list of all commands
and queries.
2.1
2.2
2.3
2.4
2.5
2.6
2.7
$PANAMAX
$MAX 74/7500-PRO
$FIRMWARE revision
if front panel button is ON, $BUTTON = ON
if front panel button is OFF, $BUTTON = OFF
if input trigger is ON, $TRIGIN = ON
if trigger input is OFF, $TRIGIN = OFF
$BANK1 = status
$BANK2 = status
$BANK3 = status
$BANK4 = status
$HC1 = status
$HC2 = status
$TRIGOUT = status
status = { ON, OFF }
if input voltage is within limits, $PWR = NORMAL
during overvoltage, $PWR = OVERVOLTAGE
during undervoltage, $PWR = UNDERVOLTAGE
during recovery, $PWR = RECOVERY
If 140V > Vin > 90: $VOLTAGE = xxx
where xxx is the input line voltage expressed in decimal format. If the
voltage is less than 100, the hundreds digit is represented with a 0.
For example, a line voltage of 92VAC would be expressed as:
$VOLTAGE = 092
If Vin > 140V: $VOLTAGE = OVERVOLTAGE
If Vin < 90V: $VOLTAGE = UNDERVOLTAGE
$CURRENT = xxx
where xxx is the input current expressed in decimal format. If the cur-
rent is less than 10, the tens digit is represented with a 0. For example,
a current of 3.3A would be expressed as:
$CURRENT = 03.3
Transmit a listing of all commands and queries.
QUERIES
Query Description Response
