11
Rack mounting
The unit can be mounted into a 19-inch standard rack (height: 7U size) if the optional rack-mounting adaptors (BT-MA1400G)
are used. Refer to the following when attaching the adaptors.
2
Remove the six screws from the monitor.
3
Attach the BT-MA1400G rack mount adapter using the
two screws which were removed in step 1 and six
screws which were removed in step 2.
Screws
1
Remove the stand from the main monitor unit.
Screws
Keep the temperature inside the rack to between +41 oF (5
o
C) and +95 oF (35 oC).
About the stand
The stand attached to the unit can be tilted forward 10° and
back 20°.
When tilting the monitor, firmly press down on the stand and
grasp the top part of the monitor.
Further, it is recommended to secure the stand using the
screw holes when it is to be permanently located.
Take care not to catch your fingers or hands when tilting the
stand.
