APPENDIX C
(cont)
X.21 Interface Pin Description
(DB-15 Female Connector)
Pin # Signal
1 . . . . . . . . . . . . Frame Ground
2 . . . . . . . . . . . . T (Transmit Data-A)
3 . . . . . . . . . . . . C (Control-A)
4 . . . . . . . . . . . . R (Receive Data-A)
5 . . . . . . . . . . . . I (Indication-A)
6 . . . . . . . . . . . . S (Signal Element
Timing-A)
7 . . . . . . . . . . . . BT (Byte Timing-A)
8 . . . . . . . . . . . . SGND (Signal Ground)
9 . . . . . . . . . . . . T/ (Transmit Data-B)
10 . . . . . . . . . . . C/ (Control-B)
11. . . . . . . . . . . . R/ (Receive Data-B)
12 . . . . . . . . . . . I/ (Indication-B)
13 ........................S/ (Signal Element
Timing-B)
14 .......................BT/ (Byte Timing-B)
21 22
APPENDIX C
(cont)
G.703 Interface Pin Assignment
(RJ45 8-Pin Modular)
Pin # Signal
1 RD+ (Receive Data Tip)
2 RD- (Receive Data Ring)
3 Not Used
4 TD- (Transmit Data Ring)
5 TD+ (Transmit Data Tip)
6 Not Used
7 Not Used
8 Not Used
