About this guide
This guide describes the SmartNode 4950 hardware, installation and basic configuration. For detailed software
configuration information refer to the SmartWare Software Configuration Guide and the available Configura-
tion Notes.
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
on page 13 provides information about router features and capabilities
•
on page 20 contains an overview describing router operation and applications
•
on page 22 provides hardware installation procedures
•
on page 27 provides quick-start procedures for configuring the SmartNode router
•
on page 36 provides information on G.SHDSL basic configuration
•
on page 41 contains information on contacting Patton technical support for assistance
•
on page 44 contains compliance information for the router
•
on page 48 contains specifications for the routers
•
on page 55 provides cable recommendations
•
on page 60 describes the router’s ports and pin-outs
•
on page 63 lists the factory configuration settings for SmartNode 4950
•
on page 65 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 4950
For best results, read the contents of this guide before you install the router.
