1996 Dec 12
3
Philips Semiconductors
Product specification
Smart card interface
TDA8001
QUICK REFERENCE DATA
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
V
DD
supply voltage
6.7
−
18
V
I
DD
supply current
idle mode; V
DD
= 12 V
−
32
−
mA
active modes; unloaded
−
45
−
mA
V
th2
threshold voltage on V
SUP
4.5
−
4.72
V
V
th4
threshold voltage on V
DD
6
−
6.5
V
V
CC
card supply voltage
including static and dynamic
loads on 100 nF capacitor
4.75
5.0
5.25
V
I
CC
card supply current
operating
−
−
−
100
mA
detection
−
−
150
−
mA
limitation
−
−
−
200
mA
V
H
high voltage supply for
V
PP
−
−
30
V
V
PP
card programming
voltage (only at TDA8001
and TDA8001T)
(P = 5, 12.5, 15 and 21 V)
including static and dynamic
loads on 100 nF capacitor
P
−
2.5%
−
P + 2.5% V
I
PP
programming current
(read or write mode)
operating
−
−
−
50
mA
detection
−
−
75
−
mA
limitation
−
−
−
100
mA
SR
slew rate on V
CC
and V
PP
(rise and fall)
maximum load capacitor 150 nF
−
0.38
−
V/
µ
s
t
de
deactivation cycle duration
75
100
125
µ
s
f
clk
clock frequency
0
−
8
MHz
P
tot
continuous total power
dissipation
TDA8001; T
amb
= +70
°
C;
see Fig.10
−
−
0.92
W
TDA8001T; T
amb
= +70
°
C;
see Fig.11
−
−
2
W
T
amb
operating ambient
temperature
0
−
+70
°
C
