1996 Dec 12 2
Philips Semiconductors Product specification
Smart card interface TDA8001
FEATURES
•
Protected I/O line
•
V
CC
regulation (5 V
±
5%, 100 mA max. with controlled
rise and fall times)
•
V
PP
generation (12.5, 15 or 21 V
±
2.5%, 50 mA max.,
with controlled rise and fall times) (only at TDA8001 and
TDA8001T)
•
Clock generation (up to 10 MHz), with synchronous
frequency doubling
•
Overload, thermal and card extraction protections
•
Current limitation in case of short-circuit
•
Idle mode and special circuitry for spikes killing during
powering on and off
•
Two voltage supervisors (digital and analog supplies)
•
Automatic activation and deactivation sequences
through an independent internal clock
•
Enhanced ESD protections on card side (4 kV min.)
•
Easy chaining for multiple card readers
•
ISO 7816 compatibility.
APPLICATIONS
•
Pay TV (multistandards conditional access system,
videoguard, newscript)
•
Multi-application smart card readers (banking, vending
machine, electronic payment identification).
GENERAL DESCRIPTION
The TDA8001 is a complete, low-cost analog interface
which can be positioned between an asynchronous smart
card (ISO 7816) and a microcontroller. It is directly
compatible with the new Datacom chip verifier.
The complete supply, protection and control functions are
realized with only a few external components, making this
product very attractive for consumer applications
(see Chapter “Application information”).
ORDERING INFORMATION
TYPE
NUMBER
PACKAGE
NAME DESCRIPTION VERSION
TDA8001;
TDA8001A DIP28 plastic dual in-line package; 28 leads (600 mil) SOT117-1
TDA8001T;
TDA8001AT SO28 plastic small outline package; 28 leads; body width 7.5 mm SOT136-1
