Princess PI1010A INSERT STOVE INSTALLATION PROCEDURE
AFTER YOU READ AND FULLY UNDERSTAND THE MATERIAL IN THIS MANUAL, YOU ARE READY TO
PROCEED WITH THE INSTALLATION OF YOUR STOVE.
Before beginning the installation, thoroughly clean and inspect the fireplace and chimney you are using.
Professional assistance is recommended, your local certified installer should be contacted to provide
installation and inspection services.
TOOLS NEEDED FOR INSTALLATION
If you are planning to install this stove yourself, you will need the tools listed below. Consult the chimney and flue
connector manufacturer's installation instructions for tools needed for chimney installation.
- 1/4" Wrench, Nut driver, or Socket with Handle.
- Medium Flat Blade Screwdriver, Phillips Screwdriver and #2 Square Drive Screwdriver
- Tape Measure.
- Carpenter's Level.
See OPTIONS section for tools needed.
STOVE ASSEMBLY
Remove all items packed in the firebox.
IF YOU HAVE NOT ALREADY DONE SO, PLEASE TAKE A FEW MINUTES TO COMPLETE THE WAR-
RANTY CARD FOUND IN THE FIREBOX AND MAIL IT TODAY.
PRODUCT INSPECTION
BLAZE KING Stoves are known for their quality materials and construction. However, mistakes occasionally oc-
cur. Inspect all parts for damage due to shipping and to be sure that all needed parts are enclosed. If you dis-
cover a part is missing or damaged, contact your dealer immediately for replacement or repair. Refer to the part
number listed on page 32
and the model and serial numbers of your stove (see the tag on the back of the stove).
COMBUSTOR ASSEMBLY, INSTALLATION
See page 26 for proper parts names. This stove is generally shipped from the factory with the combustor in-
stalled. If the combustor is not installed, follow the instructions on page 27 under Catalytic Combustor, Replace-
ment, beginning with Step 6.
FLAME SHIELD, INSTALLATION
The flame shield is a stainless steel plate, punched with many 3/8” holes. If the flame shield has fallen off during
shipping then it must be installed before the first fire. Hold it in the firebox with the triangular wings facing away.
Lift it between the loading door and the catalyst, and rest the bottom of the plate on the two pins that protrude
below the catalyst. The flame shield should rest at an angle (about 45 degrees) with its bottom near the combus-
tor, and its top near the stove front.
OPTIONAL ACCESSORIES
Gold Door—Part# Z4686G-C
REPLACEMENT PARTS
See page 32.
Preparation And Assembly
BEFORE YOU PUT YOUR STOVE IN PLACE, YOU
MUST ATTACH THE WARNING PLATE THAT WAS
INCLUDED WITH YOUR STOVE (SHOWN TO THE
RIGHT). THIS LABEL PLATE MUST BE
ATTACHED TO THE INSIDE WALL OF YOUR
FIREPLACE.
