6
Tuning the TV to Your VCR
The VCR supplies a signal to the TV via the RF coaxial cable
on channel AU28-69 or NZ21-69.
It is possible to view the video picture on your TV in the same
way that you watch TV broadcasts.
If you have connected the VCR to the TV through the Audio/
Video input sockets, then you do not need to follow the
procedure below.
For NV-HV60GL/Australia
Preparation
• Turn on the TV and the VCR.
Operations
1 Hold down [MENU]
(7) for 5 seconds or more.
2 Set the TV to an unused position which you wish to
use for your video playback.
• Tune the TV until the display
shown on the right appears on
the screen. (Please refer to the
TV manufacturers operating
instructions regarding tuning.)
3 Press [MENU] (7).
For NV-HV60GN/New Zealand
When the VCR is turned on after unpacking and
connecting the aerial cable and the mains lead, Plug in
Auto Tuning starts automatically.
Notes:
• If the VCR is turned on with the aerial not connected, all
channels are skipped. Therefore, firmly connect the aerial
and then turn the VCR off and on again to execute Plug in
Auto Tuning.
• When Auto Tuning is cancelled halfway, Auto Tuning is not
executed even if the VCR is turned off and then turned on
again. In this case, see page 7 [To Restart Plug in Auto
Tuning].
Preparation
• Turn on the TV and the VCR.
Operations
1 Set the TV to an unused position which you wish to
use for your video playback.
• Tune the TV until the display shown below appears on
the screen. (Please refer to the TV manufacturers
operating instructions regarding tuning.)
2 Press [MENU] (7).
To Change the RF output Channel
In some rare cases after tuning the TV to your VCR,
interference may be visible on the picture. To get rid of this
interference, you can manually adjust the RF output channel a
few channels up and down from the current setting. The
procedure is described below.
Operations
1 Hold down [MENU]
(7) for 5 seconds or more.
• The VCR display changes as shown below and the VCR
picture on the TV displays this pattern.
2 Enter the desired channel number (AU28-69, NZ21-69)
by [Numeric] (2) or [Channel] (32).
• Ensure that [VCR/TV] switch (22) is set to [VCR].
• Set the RF output channel of the VCR to [ ss] (RF OFF)
when the VCR is connected to the TV via the Audio/Video
cable.
Press [Channel]
(32) to display [ ss].
NV-HV60GL:
NV-HV60GN:
• It is also possible to select by pressing [Numeric] (2)
Example:
3 Press [MENU] (7) to finish the setting mode.
4 Retune your TV to the new RF channel for the VCR.
Note:
• Even if the RF output channel has been changed, it is not
necessary to perform Auto Tuning.
Panasonic VCR
END: MENU
END: MENU
AUTO TUNING IS
COMPLETED.
CH 22 SEARCH
END: MENU
21
AUTO TUNING
IN PROGRESS,
PLEASE WAIT.
During Plug in Auto Tuning After Plug in Auto Tuning
Panasonic VCR
END: MENU
Example for NV-HV60GL Example for NV-HV60GN
28
ss
… 69
(RF OFF)
21
ss
69
(RF OFF)
2 8 28:
