PB Heat Gas Boiler User Manual
Page 42
40
Boiler
Model
Input Btu/hr
DOE Heating
Capacity³
Btu/hr
Net I=B=R
Rating¹’²
Btu/hr
Seasonal
Efficiency³
AFUE %
Shipping
Weight
Lbs.
PI-T50
18,000 to 50,000
16,000 to 46,000
40,000
92
58
PI-T80
19,000 to 80,000
17,000 to 74,000
64,000
92
58
PI-80
27,000 to 80,000
25,000 to 74,000
64,000
92
75
PI-140
46,000 to 140,000
43,000 to 129,000
112,000
92
101
PI-199
66,000 to 199,000
61,000 to 183,000
159,000
92
111
Boiler
Model
Fan Speed – RPM
High Fire
Ignition
Low Fire
PI-T50
3200
3000
1250
PI-T80
4700
3000
1200
PI-80
4600
4600
2000
PI-140
4300
2000
1400
PI-199
6000
3745
2100
Table 10.1: Boiler Ratings
Table 10.2: Combustion Air Fan Speed
1.
Net I=B=R ratings are based on an allowance of 1.15.
2.
Consult factory before selecting a boiler for installations having unusual piping and pickup requirements, such as
intermittent system operation, extensive piping systems, etc.
3.
Heating Capacity and Annual Fuel Utilization Efficiency (AFUE) ratings are based on U.S. Government Testing.
Note: These values are subject to change without notice.
BOILER DIMENSIONS & RATINGS
Boiler
Model
Supply &
Return Conn.
(NPT)
Relief Valve
Outlet
(NPT)
Gas Supply
Conn.
(NPT)
Air Inlet &
Vent Conn.
(Sch 40 PVC)
Condensate
Drain Pipe
(NPT)
PI-T50
1-1/4"
3/4"
3/4"
2"
3/4"
PI-T80
1-1/4"
3/4"
3/4"
2"
3/4"
PI-80
1-1/4"
3/4"
3/4"
3"
3/4"
PI-140
1-1/4"
3/4"
3/4"
3"
3/4"
PI-199
1-1/4"
3/4"
3/4"
3"
3/4"
Table 10.3: Connection Sizes
