- 2 -
Point-to-MultiPoint)
• Provide Windows-based configuration utility and Web Configuration
1.4 Specification
Standard IEEE 802.11b Compliant
Signal Type DSSS (Direct Sequence Spread Spectrum)
Modulation QPSK / BPSK / CCK / PBCC
Port One 10/100BASE-TX
Antenna 1 x Dipole Antenna
Data Encryption 64 bit / 128 bit / 256bit WEP encryption
Frequency 2.4GHz - 2.4835GHz
Channel 11 Channels (US, Canada)
13 Channels (Europe)
14 Channels (Japan)
Data Rate 1/2/5.5/11/22Mbps, 22Mbps+4X
LED Indicators Power, WLAN, LAN
Power Requirement 5V DC, 2.5A
Temperature Operating :0 ~ 55 degree C
Storage: -10 ~ 70 degree C
Humidity Operating: 5 ~ 95%
Storage: 0 ~ 95% Non-Condensing
Dimensions 196x120x31mm
Output Power 17dBm ±1dBm
Antenna Gain 2dBi
Antenna Connector Reversed Polarity SMA Male
