46 PowerScan ™ Scanner
Label Transmit Configuration (
RS-232 and Keyboard Wedge Interfaces only)
If you need to send information in addition to bar code label data, the
scanner can be configured to transmit Global Prefixes (also known as
preambles), Global Suffixes (also known as postambles), and symbol-
ogy specific identifier characters (termed Label I.D.).
Prefix, Suffix, and Label I.D.
The table below shows examples of how Prefix, Suffix, and Label I.D.
characters can be applied.
Column three contains the label data, while columns one, two, four
and five contain the additional characters added by way of the Prefix,
Label I.D. as Prefix, Label I.D. as Suffix, and Global Suffix respectively.
The last column shows the resulting data that will be transmitted when
the additional characters are applied.
Table 3. Prefix, Suffix, Label I.D. Examples
NOTE
Using this feature requires a thorough understand-
ing of your specific system requirements. If you
have questions or need assistance with these fea-
tures, call your system specialist or PSC technical
support.
Global
Prefix
(00 = No
Char.)
Label I.D. as
Prefix
Label Data
Label I.D. as
Suffix
Global Suffix
(00 - No
Char)
1st
Char
2nd
Char
1st
Char
2nd
Char
(Examples)
1st
Char
2nd
Char
1st
Char
2nd
Char
Resulting Label
Format
00 00 None 0998875 None 00 00 0998875
50 51 None 0011223344 None 000 000 PQ0011223344
00 00 46 46 00210126 None 00 00 FF00210126
50 51 41 00
a
a. No second character
00210126 None 00 00 PQA210126
00 00 None $99.95 25 00 a 00 00 $99.95%
50 51 None 998875 25 00 a 00 00 PQ998875E
00 00 None 101234567891 None 53 57 10123456789SW
50 51 None Code39Test None 53 57 PQCode39TestSW
00 00 45 00 a Code128 None 53 00 ECode128S
50 00 45 46 0998875 None 53 57 PFF09988875SW
00 00 None 0998875 46 46 53 57 0998875FFSW
50 51 None 0011223344 46 00* 53 57 PQ0011223344FSW
