1999 Oct 12 3
Philips Semiconductors Product specification
IC card interface TDA8002C
QUICK REFERENCE DATA
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
Supplies
V
DD
supply voltage 3.0
−
6.5 V
I
DD(lp)
supply current low-power
− −
150
µ
A
I
DD(idle)
supply current Idle mode; f
CLKOUT
= 10 MHz
− −
5 mA
I
DD(active)
supply current active mode; V
CC(O)
= 5 V;
f
CLKOUT
= 10 MHz
f
CLK
= LOW; I
CC
= 100
µ
A
− −
8 mA
f
CLK
= 5 MHz; I
CC
= 10 mA
− −
50 mA
f
CLK
= 5 MHz; I
CC
= 55 mA
− −
140 mA
active mode; V
CC(O)
= 3 V;
f
CLKOUT
= 10 MHz
f
CLK
= LOW; I
CC
= 100
µ
A
− −
8 mA
f
CLK
= 5 MHz; I
CC
= 10 mA
− −
50 mA
f
CLK
= 5 MHz; I
CC
= 55 mA
− −
140 mA
Card supply
V
CC(O)
output voltage active mode for V
CC
= 5 V
I
CC
< 55 mA; DC load 4.6
−
5.4 V
I
CC
= 40 nAs; AC load 4.6
−
5.4 V
active mode for V
CC
= 3 V
I
CC
< 55 mA; DC load 2.76
−
3.24 V
I
CC
= 40 nAs; AC load 2.76
−
3.24 V
General
f
CLK
card clock frequency 0
−
12 MHz
t
de
deactivation sequence duration 60 80 100
µ
s
P
tot
continuous total power dissipation
TDA8002CT/x T
amb
=
−
25 to +85
°
C
− −
0.56 W
TDA8002CG T
amb
=
−
25 to +85
°
C
− −
0.46 W
T
amb
ambient temperature
−
25
−
+85
°
C
