1999 Oct 12 21
Philips Semiconductors Product specification
IC card interface TDA8002C
Notes
1. It may be necessary to connect capacitors from XTAL1 and XTAL2 to ground depending on the choice of crystal or
resonator.
2. When the oscillator is stopped in mode 1, XTAL1 is set to HIGH.
3. The transition time and duty cycle definitions are shown in Fig.15;
4. CLKOUT transition time and duty cycle do not need to be tested.
5. PRES and CMDVCC are active LOW; RSTIN, PRES and CS are active HIGH.
δ
t
1
t
1
t
2
+
--------------- =
Fig.15 Definition of transition times.
handbook, full pagewidth
MGE741
10%
90% 90%
10%
tr tf
t1 t2
VOH
1/2 VCC
VOL
