UHF amplifier module BGY2016
CHARACTERISTICS
T
mb
= 25
°
C; V
S1
= 5 V; V
S2
= 26 V; P
L
= 16 W; Z
S
= Z
L
= 50
Ω
unless otherwise specified.
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
f frequency 1805
−
1990 MHz
I
S1
supply current
−
80
−
mA
I
S2
supply current P
D
<
−
60 dBm
−
430
−
mA
P
L
load power P
D
< 20 mW 16
− −
W
G
p
power gain 28
−
35 dB
∆
G
p
in band gain variation f = 1805 to 1880 MHz; P
L
= 5 W
− −
2 dB
f = 1930 to 1990 MHz; P
L
= 5 W
− −
2 dB

G
p1
- G
p2

gain expansion G
p1
at P
L
= 160 mW;
G
p2
at P
L
= 5 mW
− − ±
1 dB
η
efficiency P
L
= 16 W 30
− −
%
H
2
second harmonic P
L
= 16 W
− − −
35 dBc
H
3
third harmonic P
L
= 16 W
− − −
40 dBc
VSWR
in
input VSWR
− −
2 : 1
stability VSWR
≤
2 : 1 through all phases;
P
L
≤
16 W; V
S2
= 25 to 27 V
− − −
60 dBc
reverse intermodulation P
carrier
= 16 W; P
reverse
=
−
40 dBc;
f
i
= f
c
±
200 kHz
− − −
53 dBc
B AM bandwidth corner frequency = 3 dB;
P
carrier
= 16 W; modulation = 20%
2
− −
MHz
ruggedness VSWR
≤
5 : 1 through all phases no degradation
