30 DRB1558-A
En 30
Specifications
General
Power requirements ................................................................................ AC 120 V, 60 Hz
Power consumption ...................................................................................................23 W
Power consumption (standby) .................................................................................0.4 W
Main unit weight ........................................................................................ 6.1 kg (13.5 lb)
Max. dimensions ...............................................265 mm (W) × 107.9 mm (H) × 403 mm (D)
(10.4 in. (W) × 4.2 in. (H) × 15.9 in. (D))
Tolerable operating temperature ............................ +5 °C to +35 °C (+41 °F to +95 °F)
Tolerable operating humidity ..........................................5 % to 85 % (no condensation)
Audio Section
Sampling rate .......................................................................................................... 48 kHz
A/ D, D/ A converter .................................................................................................. 24 bits
Frequency characteristic
CD .......................................................................................................20 Hz to 20 kHz
S/ N ratio (rated output)
PHONO ..............................................................................................................92 dB
CD .....................................................................................................................106 dB
MIC .....................................................................................................................84 dB
Total harmonic distortion (CD — MASTER1)...................................................... 0.004 %
Standard input level / Input impedance
PHONO ...............................................................................................–52 dBu/ 47 kW
CD ........................................................................................................ -12 dBu/ 47 kW
MIC ...................................................................................................... -52 dBu/ 47 kW
AUX .....................................................................................................–12 dBu/ 29 kW
Standard output level / Load impedance / Output impedance
MASTER1 ....................................................................+6 dBu/ 10 kW/ 10 W or lower
MASTER2 ................................................................................ +2 dBu/ 10 kW/ 330 W
BOOTH ........................................................................+6 dBu/ 10 kW/ 10 W or lower
PHONES ....................................................................+5.4 dBu/ 32 kW/ 10 W or lower
Rated output level / Load impedance
MASTER1 ......................................................................................... +24 dBu/ 10 kW
MASTER2 ......................................................................................... +20 dBu/ 10 kW
Crosstalk (CD) ...........................................................................................................86 dB
Channel equalizer characteristic
HI ............................................................................................ –
∞
to +6 dB (13 kHz)
MID .......................................................................................... –
∞
to +6 dB (1 kHz)
LOW ......................................................................................... –
∞
to +6 dB (70 Hz)
Microphone equalizer characteristic
HI ..................................................................................... –12 dB to +12 dB (10 kHz)
LOW ................................................................................ –12 dB to +12 dB (100 Hz)
Input / Output terminals
PHONO input terminal
RCA pin jack ......................................................................................................2 sets
CD input terminal
RCA pin jack ......................................................................................................2 sets
MIC input terminal
XLR connector/ phone jack (Ø 6.3 mm) ............................................................. 1 set
AUX input terminal
RCA pin jacks ..................................................................................................... 1 set
MASTER output terminal
XLR connector .................................................................................................... 1 set
RCA pin jacks ..................................................................................................... 1 set
BOOTH output terminal
TRS phone jack (Ø 6.3 mm) ............................................................................... 1 set
PHONES output terminal
Stereo phone jack (Ø 6.3 mm) ........................................................................... 1 set
USB terminal
B type .................................................................................................................. 1 set
! The specifications and design of this product are subject to change without notice.
! The software screens used in these operating instructions are from the
development stage and may differ from the actual screens.
