B) Receiver unit

19 Power button

switches the receiver between stand-by and on. When the receiver unit
is turned on or off the transmitter unit is automatically turned on or off
as well.

20 Power light

lights red in stand-by mode, green when power is on, flashes when
receiving remote control commands

21 Remote control signal receiver

receives remote control commands which are sent to the transmitter
unit to control the video sources.

22 Input source up (+) / down (-) buttons

selects one of the four video sources connected to the transmitter unit
for viewing on the third TV

23 Transmission channel switch

switches the frequency channel of the audio/video signal to minimize
interference.

24 SCART output connector

for connection to the third TV

25 DC power input

for connection to the mains

26 SCART cable
27 Power adapter
28 Remote control antenna
