SPECIFICATIONS

Pick-up device:

752 (H) x 582 (V) pixels, Interline transfer CCD

Scanning area:

4.8 (H) x 3.6 (V) mm (Equivalent to 1/3” pick-up tube)

Scanning:

625 lines/50 fields/25 frames

Horizontal:

15.625 kHz

Vertical:

50 Hz

Synchronization:

Internal, Line-lock (only 24 V AC or 220-240 V AC), or Multiplexed vertical drive
(VD2)

Video output:

1.0 V [P-P] PAL composite 75

Ω/BNC connector

Horizontal resolution:

480 lines

Signal-to-noise ratio:

50 dB (Equivalent to AGC Off, weight On)

Minimum illumination:

1.0 lx (0.1 footcandle) (WIDE),

Detail:

SHARP or SOFT, selectable

White balance:

ATW

Lens Mount:

CS-mount

Lens

Focal length:

3.8 mm - 8 mm

Maximum aperture ratio:

1:1.4 (Wide), 1:1.8 (Tele)

Angular field of view:

Horizontal: 35.6 ° - 73.6 °
Vertical:

26.6 ° - 53.4 °

Focusing range:

1.2 m -

∞ (3.9 ft - ∞)

Ambient operating temperature:

–10 °C - +50 °C (14 °F - 122 °F)
–30 °C - +50 °C (–22 °F - 122 °F)
(When the optional heater unit built in)

Ambient operating humidity:

Less than 90 %

Power source and

Power consumption:

WV-CW244FE: 12 V DC, 265 mA (Camera)

24 V AC 50 Hz, 3.0 W (Camera)
24 V AC 50 Hz, 12.1 W (Heater unit)
