14
FIG. 22
FORWARD MOTION
(INSIDE) V-BELT
ENGINE PULLEY
REVERSE
IDLER ARM
REVERSE
IDLER PULLEY
IDLER
ARM PIN
FIG. 21
FORWARD
IDLER PULLEY
REVERSE
IDLER
PULLEY
ENGINE
PULLEY
FRONT VIEW REFERENCE
REVERSE (OUTSIDE) V-BELT
FORWARD MOTION (INSIDE) V-BELT
TRANSMISSION
PULLEY
BELT GUARD
BOLT
BELT
GUIDE
REVERSE
IDLER PULLEY IDLER
ARM PIN
ENGINE
PULLEY
REVERSE (OUTSIDE)
V-BELT
FORWARD IDLER
PULLEY
REVERSE
IDLER PULLEY
ENGINE PULLEY
BELT GUIDE
TRANSMISSION
PULLEY
BELT GUIDE
FORWARD
IDLER PULLEY
SERVICE AND ADJUSTMENTS
ENGINE
TO ADJUST CARBURETOR
The carburetor has been preset at the factory and adjust-
ment should not be necessary. However, engine perfor-
mance can be affected by differences in fuel, temperature,
altitude or load. If the carburetor does need adjustment,
contact your nearest authorized service center/department
IMPORTANT: NEVER TAMPER WITH THE ENGINE
GOVERNOR, WHICH IS FACTORY SET FOR PROPER
ENGINE SPEED. OVERSPEEDING THE ENGINE ABOVE
T H E F A C T O R Y H I G H S P E E D S E T T I N G C A N B E
DANGEROUS. IF YOU THINK THE ENGINE-GOVERNED
HIGH SPEED NEEDS ADJUSTING, CONTACT YOUR
N E A R E S T A U T H O R I Z E D S E R V I C E C E N T E R /
DEPARTMENT, WHICH HAS THE PROPER EQUIPMENT
A N D E X P E R I E N C E T O M A K E A N Y N E C E S S A R Y
ADJUSTMENTS.
