Other connections 12
72
En
SCART pin assignment
The diagram below shows the SCART 21-pin
connector assignment. This connector
provides the video and audio signals for
connection to a compatible colour TV or
monitor.
Pin
No.
Assignment
Pin
No.
Assignment
1 Audio R OUT 12 No
connection
2 Audio R IN 13 GND (video)
3 Audio L OUT 14 GND (video)
4 GND (audio) 15 R or C OUT
5 GND (video) 16 BLANK OUT
6 Audio L IN 17 GND (video)
7 B OUT 18 GND (video)
8 Status 19 Video or Y
OUT
9 GND (video) 20 No
connection
10 No
connection 21 GND (video)
11 G OUT
