26
English
Maintenance
Cleaning the Cabinet
• Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution containing
alcohol, spirits, ammonia or abrasives.
Cleaning Discs
• When a disc becomes dirty, clean it
with a cleaning cloth. Wipe the disc
from the center out.
• Do not use solvents such as benzine,
thinner, commercially available
cleaners, or antistatic spray intended
for analog records.
Cleaning the CD lens
• After prolonged usage, dirt or dust may accumulate at
the CD lens. To ensure good playback quality, clean the
CD lens with Philips Magnavox CD Lens Cleaner or any
commercially available. Follow the instructions supplied
with the Lens Cleaner.
Cleaning the Heads and the Tape Paths
• To ensure good recording and playback quality, clean the
heads, the capstan(s), and pressure roller(s) after every
50 hours of tape operation.
• Use a cotton swab slightly moistened with cleaning
fluid or alcohol.
• You can also clean the heads by playing a cleaning tape
through once.
Demagnetizing the heads
• Use a demagnetizing tape available at your dealer.
Specifications
AMPLIFIER
Output power
FW45C/FW320C (3
Ω
, 1 kHz, 10% THD) . 2 x 5 W RMS (1)
FW55C (6
Ω
, 1 kHz, 10% THD) ..... 2 x 10, 2 x 2 W RMS (1)
Signal-to-noise ratio .....................................
≥
67 dBA (IEC)
Frequency response ..................................... 50 – 15,000 Hz
Input sensitivity
Aux In .................................................................... 700 mV
Output
Speakers (for FW45C/FW320C only) ......................
≥
3
Ω
Speakers (for FW55C only) ......................................
≥
6
Ω
Surround Speakers (for FW55C only) ......................
≥
6
Ω
Headphones .............................................. 32
Ω
– 1000
Ω
(1) ± 1 dB
CD PLAYER
Number of programmable tracks ..................................... 40
Frequency range ........................................... 20 – 20,000 Hz
Signal-to-noise ratio ..............................................
≥
80 dBA
Channel separation .....................................
≥
60 dB (1 kHz)
Total harmonic distortion ..................................... < 0.003%
TUNER
FM wave range ........................................... 87.5 – 108 MHz
AM wave range ........................................... 530 – 1700 kHz
Number of presets ............................................................ 40
Antenna
FM ....................................................... 300
Ω
dipole wire
AM .............................................................. Loop antenna
TAPE DECK
Frequency response
Normal tape (type I) ....................... 80 – 12,500 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) ...........................................
≥
48 dBA
Wow and flutter .................................................
≤
0.4% JIS
SPEAKERS (for FW45C/FW320C only)
System ............................................ double port bass reflex
Impedance ..................................................................... 3
Ω
Woofer ........................................................ 1 x 4" full range
Dimensions (w x h x d) ...................... 210 x 310 x 188 (mm)
Weight ............................................................... 2.3 kg each
SPEAKERS (for FW55C only)
System ............................................ double port bass reflex
Impedance ..................................................................... 6
Ω
Woofer ........................................................ 1 x 4" full range
Dimensions (w x h x d) ...................... 210 x 310 x 233 (mm)
Weight ............................................................... 2.3 kg each
SURROUND SPEAKERS (for FW55C only)
System ......................................................... closed satellite
Impedance ..................................................................... 6
Ω
Surround Speaker Driver ............................ 1 x 3” full range
Dimensions (w x h x d) ........................ 178 x 90 x 178 (mm)
Weight ............................................................. 0.85 kg each
GENERAL INFORMATION
Material/finish .................................................. Polystyrene
AC Power ........................................................ 120 V / 60 Hz
Power Consumption
Active
FW45C/FW320C .................................................... 18 W
FW55C ................................................................... 35 W
Standby
FW45C/FW320C .................................................
≤
11 W
FW55C ................................................................
≤
15 W
Dimensions (w x h x d) ...................... 265 x 310 x 330 (mm)
Weight
(without speakers) ......................................... 5.2 kg
Subject to modification
