88 installation – Pioneer Super Tuner III AVM-P9000 User Manual
Page 89
88
Installation
V.SEL cable (supplied with the display)
There is no need to connect a
display that does not feature these
jacks or cables.
*1
Multi-CD player
(sold separately)
*1
Blue
Blue
Black
Display with an IP-BUS
cable (sold separately)
Gray
Green
When connecting a
Display featuring non
IP-BUS connection,
connections within the
dotted lines are not
necessary. So please
connect the two IP-BUS
connectors (*1) directly
to each other.
20 pin cable (supplied with the display)
IP-BUS cable
(supplied with the display)
