66
Fine Adjusting Audio (Expert)
8. Adjust the selected option by moving the joy-
stick up/down.
The selectable options are adjustable in the following
limits:
As well, “Frequency” differs in adjustable range from
Band to Band.
Option Adjustable Range
Level –12 dB to +12 dB
Frequency Low: 40/80/100/160 Hz
Mid: 200/500/1k/2k Hz
High: 3.15k/8k/10k/12.5k Hz
Q Factor 2W/1W/1N/2N
9. Select “Band” by moving the joystick.
10. Repeat steps 6 – 9 for other bands.
Note:
• If you make adjustments when a curve other than “CUSTOM” is selected, “CUSTOM”
appears and the adjusted curve is stored in “CUSTOM”. (See page 52.)
• For how to select EQ curves other than “CUSTOM”, refer to “Equalizer Curve”.
Continued overleaf.
