Installation
Connecting to a Sold Separately Power Amp
This product can be connected to a sold separately power amp using the RCA output jacks.
83
Front output
Rear output
Subwoofer
output
Center output
This Product
System remote control
RCA cables
(sold separately)
System remote control
System remote control
System remote control
Blue/white
To system control terminal of the power
amp or Auto-antenna relay control terminal
(max. 300 mA 12V DC).
Rear speaker
Center speaker
Front
speaker
Front speaker
Subwoofer
Rear speaker
Perform these connections when using a different amp (sold separately).
Power amp
(sold separately)
Power amp
(sold separately)
Power amp
(sold separately)
Power amp
(sold separately)
